• Plastic LC-SC Fiber Adapter , Singlemode Fiber Optic Connector Adapters
Plastic LC-SC Fiber Adapter , Singlemode Fiber Optic Connector Adapters

Plastic LC-SC Fiber Adapter , Singlemode Fiber Optic Connector Adapters

Product Details:

Place of Origin: China
Brand Name: FOCABLE
Certification: RoHS Compliant, ISO Certificate
Model Number: LC-SC Fiber Optic Adapter

Payment & Shipping Terms:

Minimum Order Quantity: 100PCS
Packaging Details: 50PCS/Blister Box
Supply Ability: 90000PCS/Month
Get Best Price Contact Now

Detail Information

Sleeve Material: Zirconia Ceramic Sleeve Adapter: LC-SC
Cores: Simplex Material: Plastic
Cap Color: White Mode: Singlemode
High Light:

fiber optic cable adapter

,

fiber optic connector adapters

Product Description

Plastic LC-  SC Fiber Adapter , Singlemode Fiber Optic Connector Adapters

The LC - SC Hybrid Adapter offers a solution for any hybrid applications where SC interconnect systems are incorporated into LC system configurations or vice versa.

The adapter’s high-precision sleeve enables reliable ferrule mating of the SC and LC ferrule diameters, ensuring low insertion and return loss.



Hybrid fiber optic adapter LC-FC and LC-SC provides the connection between the fiber optic patch cord or pigtails. Fiber optic adapters (also called couplers) are designed to connect two fiber optic cables together. They come in versions to connect single fibers together (simplex), two fibers together (duplex), or sometimes four fibers together (quad).

Adapters are designed for multimode or singlemode cables. The singlemode adapters offer more precise alignment of the tips of the connectors (ferrules). It is ok to use singlemode adapters to connect multimode cables, but you should not use multimode adapters to connect singlemode cables. This can cause misalignment of the small singlemode fibers and loss of signal strength (attenuation).



APPLICATIONS

Network environments

Telecommunications networks

Metro networks



FEATURES

High-precision sleeve

Compact design

High performance



Specification:

Insertion Lose≤0.3 dB

Interchangeability≤0.2 dB

Repeatability(500 times) ≤0.2 dB

Operating Temperature -10 - +75℃

Storage Temperature -40 - +85℃



Ordering Information

Interface

Adapter Type

Color

Fiber Type

Cores

Sleeve

P-PC

FC-FC

B-Blue

SM

Simplex

Zirconia

A-APC

SC-SC

B-Beige

MM 50/125um

Duplex

Bronze



LC-LC

G-Green

MM 62.5/125um

4cores





ST-ST

X-Customized

MM OM3







MU-MU











MTRJ-MTRJ











E2000-E2000











Hyrbid
