12 Colors Fiber Optic Pigtail multimode LC UPC For ODF and Patch Panel

12 Colors Fiber Optic Pigtail multimode LC UPC For ODF and Patch Panel

Product Details:

Place of Origin: China
Brand Name: FOCABLE
Certification: ISO, RoHS Compliant
Model Number: LC Fiber Optic Pigtail 12Colors

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Packaging Details: 1PCS/Blister Box
Get Best Price Contact Now

Detail Information

Cable: LSZH Color: 12colors
Fiber: SM Inner Diameter: 0.9mm
Connector: LC Length: 1.5M
High Light:

fiber optic pigtail connector

,

optical fiber pigtail

Product Description

12 Colors Fiber Optic Pigtail multimode LC UPC For ODF and Patch Panel

Fiber Optic Pigtail is a length fiber cable with connectors fixed on one end. If both sides of the connector or its end-face are different, we call it hybrid patch cord. According to the transmission medium, it divides Single Mode and Multi Mode; According to the connector structure type, it divides FC, SC, ST, MU, D4, LC etc.; According to the polished ceramic end-face, it divides PC, UPC and APC.



Features
Simplex, and multi-fiber assemblies are available

PC or APC finish
Compliant with Telcordia GR-326-CORE specification
Applicable connector: FC, SC, ST, LC…
Cable material: PVC, LSZH,

Fiber Type: SM, MM OM1, OM2 or OM3 optional
Cable size: Φ 0.9mm, Φ 2.0mm, Φ 3.0mm



Application
Test equipment
Optical CATV & LAN
Telecommunication networks
Optical communication networks



Specifications

Mode Single mode Multimode
Polish UPC APC PC
Insertion Loss ≤0.3dB ≤0.3dB ≤0.3dB
Return Loss ≥55dB ≥65dB ≥35dB
Interchangeability ≤0.2dB
Salt Spray ≤0.1dB
Repeatability ≤0.1dB (1000 times)
Vibration ≤0.2dB (550Hz 1.5mm)
Temperature ≤0.2dB (-40+85 sustain 100 hours)
Humidity ≤0.2dB (+25+65 93 R.H.100 hours)
Apex Offset 0μm ~ 50μm
Radius of Curvature 7mm ~ 25mm



Ordering Information

Cores Count

01=simplex, 02=duplex, ..., 06=6cores, ..., 12=12cores, 24=24cores

Fiber Type

1=G652D, 2=G657A, 3=OM3,50/125um 4=OM4 5=OM1, 62.5/125um,   6=OM2, 62.5/125um

Cable Outer Diameter

L=900µm Loose or tight tube, S=2.0mm, R=3.0mm, X=others

Cable Length

0.5-20M=0.5--20m, X=Others

Connector Type

FU=FC/UPC, FA=FC/APC, SU=SC/UPC, SA=SC/APC, ST=ST/UPC, LU=LC/UPC, LA=LC/APC, 00=None, X=Others



12 Colors Fiber Optic Pigtail multimode LC UPC For ODF and Patch Panel 0



Fiber Optic Pigtail, Optical Fiber Pigtail, Fiber Pigtail, Fiber Pigtails
